Second, Install the Printer Driver
In Windows, use the Add Printer feature to install and configure a SuperScript 4400 printer driver in each
workstation that will access the network printer.
note:
SuperScript 4400 printer drivers are on the Solutions CD that comes with the printer.
Specify that the printer will be attached as a Network Printer, and set the Port to the printer queue you just
created. (The Windows NT 4.0 driver installs automatically to LPT1:. After installation, you can manually reset the
port to your NetWare queue.)
Third, use MAP and the NIC Configuration Menu to Configure the NIC
Now you must specify the Print Server Name, Preferred NDS Context, and Preferred NDS Tree using the NIC
Configuration Menu network administration options. Continue with the instructions below, to do this.
1. Run MAP.
a. If you have not yet installed MAP, follow the instructions on page xx.
b. In Windows 95/98 or Windows NT 4.0, click the Start button. Select MAP from the program group you
specified during installation. When MAP starts, a list of all available units on the network is displayed by
unit serial number.
2. Select the NIC to configure.
a. Click on a NIC in the list to display its NIC Configuration Menu.
note:
You can also use a web browser such as Netscape Navigator or Internet Explorer, to access the NIC
Configuration Menu. Enter the NIC's IP address as the URL, for example, http://131.241.54.16. The IP address is
listed as "Protocol Address" on the Network Settings page.
3. NetWare 4.x (NDS) Configuration
a. On the NIC Configuration Menu, click the Network Administration button to display options for
configuring the NIC.
b. Click on NetWare Setup in the Protocols column.
c. In the NetWare Configuration dialog box that appears, enter a name in the Print Server Name field, enter a
name in the Preferred NDS Context field, and enter a name in the Preferred NDS Tree field. (Leave the
Preferred File Server field blank.)
d. Enter the password and click on the Accept Settings button. (The default password is sysadm.)
4. Confirm Successful Configuration.
a. In the Systems column, click on Reset.
After the Reset, the program advises waiting 2 minutes before reconnecting, but the NIC may be available
sooner.
b. Go back to the NIC Configuration Menu, click the Network Administration button. Then, in the System
column, click on Unit Status.
c. In the dialog box that appears, scroll down to display the NetWare Status. The Queue Status should be
Attached.
d. If the Queue Status is not shown as Attached, please verify that the entries for Print Server Name,
Preferred NDS Context, and Print Server Password match those defined in NWADMIN.
