Chapter 7
7. Transfer Ribbon Mechanism
7.1 Description
32
The thermal transfer ribbon mechanism is standard, but can be
omitted on special order. The mechanism consists of three main
units:
• Ribbon supply unit (see Chapter 7.2)
• Ribbon rewind unit (see Chapter 7.3)
• Ribbon-end sensor (see Chapter 7.4)
Ribbon Rewind Unit
Intermec EasyCoder 501 XP – Service Manual Ed. 4
Ribbon Supply Unit
Ribbon End Sensor
