8.2 Platen Roller, cont.
Stepper Motor
#T20 Torx Screw
Belt to Platen Roller
Pulley
Ball Bearing
Plastic Bearing
Intermec EasyCoder 501 XP – Service Manual Ed. 4
In the illustration below, the upper parts of the print unit and the
label stop sensor have been omitted to improve visibility.
#T20 Torx Screw
Spacer
Platen Roller
Plastic Bearing
Ball Bearing
Bracket
#T20 Torx Screw (1)
Chapter 8 Print Unit
Belt to Ribbon Rewind Unit
43
