13.3 Main Parts
Power Supply
(hidden)
CPU Board
Intermec EasyCoder 501 XP – Service Manual Ed. 4
This illustration shows the complete electronics compartment, but
with the Centronics interface board removed to improve the view
of the CPU board.
Ribbon Supply Unit
Liner/Batch Takeup Motor
Chapter 13 Electronics Compartment
Ribbon Rewind Unit
Print Unit Stepper Motor
85
