CHAPTER 13
Effect Mode Options Descriptions

Pan and Scan

Object Effect Global Effect
Effect Mode parameter DMX value = 255
This effect Zooms into a still image and then, by changing position, you can pan across the
image horizontally and vertically. It only functions on image sizes greater than 1024 x 1024 in
at least one direction.
Modifier 1: Adjusts the horizontal pan position from 0=left edge to 255 (100%) = right edge of
the image. The default DMX value of 128 (50%) = no adjustment.
Modifier 2: Adjusts the vertical pan position from 0 = bottom edge to 255 (100%) = top edge
of the image. The default DMX value of 128 (50%) = no adjustment.
Modifier 3: The default DMX value is 0 = no zoom. Increasing the value, increases the zoom
into the image to a maximum at a value of 255 (100%). The total Zoom range is proportional to
the image size.
Tip: Although you can apply this effect in several different modes (global, graphic and visual),
the modifier channel adjustments will only function if there is enough "room" left on the image
to move. In most cases the first application of this effect will be the only one to have an effect.
NOTE: This effect is also available as a Visual Mode adjusted with 2 Modifier
parameters, (see Pan and Scan on page 99).
DL.3 Digital Light User Manual 215
