CHAPTER 13
Effect Mode Options Descriptions
Modifier 2: The first 20 DMX values are assigned to the following Matte pattern options:
Modifier 3: This parameter determines the texture for the Matte mode selected with the
Modifier 1 parameter.
Modifier 1
DMX
DMX Value
value
0 - 3 NA
0
1
2
3
10
11
4 - 9
12
13
20
21
22
23
10 - 11 0-255 Color selected as a look up value from an internal gradient.
214
Not Used
Graphic Object 1 texture without applied Effects
Graphic Object 1 texture including its first applied Effect
Graphic Object 1 texture including its first two applied Effects
Graphic Object 1 texture including its first three applied Effects
Graphic Object 2 texture without applied Effects
Graphic Object 2 texture including its first applied Effect
Graphic Object 2 texture including its first two applied Effects
Graphic Object 2 texture including its first three applied Effects
Graphic Object 3 texture without applied Effects
Graphic Object 3 texture including its first applied Effect
Graphic Object 3 texture including its first two applied Effects
Graphic Object 3 texture including its first three applied Effects
Modifier 3
Action
