High End Systems DL.3 User Manual page 145

DMX
Effect Mode Name/Description
Value
ShakeNBake introduces a random vibration
61
effect
Slats, Vertical renders the image in offset
62
vertical slats
Slats, Horizontal renders the image in offset
63
horizontal slats
Downward Vertical Streaks "pulls" the image
80
down
81 Gaussian Blur
82 Sharpen
83 Flip
UV to Gray turns everything in the image gray
84
except for a selected UV chroma coordinate
UV to Transparent turns the image transparent
85
except for a selected UV chroma coordinate.
UV Select to Transparent turns only a selected UV
86
chroma coordinate in the image transparent
HS to Gray retains selected hue and saturation,
87
and turns everything else gray.
HS to Transparent retains selected hue and
88
saturation, and turns everything else transparent.
HS Selected To Transparent makes selected hue
89 and saturation transparent with the rest of the
image unchanged
Texture Shift shifts texture coordinate by color
90
value.
91 Lens Grid views texture through grid of lenses
Edge Detect, BW2 creates a pencil line drawn
92
effect
Film Burn/Unburn create a burn pattern on the
93
94 Film Noise creates an "aged" film effect
Particle System 1 converts image to a particle
95
pattern
DL.3 Digital Light User Manual
Adjustments
Modifier 1 Modifier 2
Horizontal Vertical
Shake Shake
Number
Vertical
Displacement
of Slats
Number
Horizontal
Displacement
of Slats
Streak
Vertical Start
Position
Angle
Sample
Number of
Filter Passes
Distance
Sample Number of
Distance Filter Passes
Horizontal Vertical
Flip Flip
U Coordinate V Coordinate
U Coordinate V Coordinate
U Coordinate V Coordinate
Hue Saturation
Coordinate
Coordinate
Hue Saturation
Coordinate Coordinate
Hue Saturation
Coordinate Coordinate
Horizontal Vertical
Shift Shift
Magnification Edge Shading
Sample Edge Threshold
Distance Comparison
Burn/Unburn Film
Rate Blackening
Push to Sepia
Noise Rate
add Jitter
Emitter Trail
Type Length
CHAPTER 11
Global Functions
Modifier 3
Scale
Fade from
Normal to Slats
Fade from
Normal to Slats
Fade from
Normal to
Streak
Scales the
Effect
Scales the
Sharpen Effect
Not Used
Tolerance
Tolerance
Tolerance
Tolerance
Tolerance
Tolerance
Color
and Scale
# of Lenses
Detected
Edge Scaler
Burn
Pattern
Noise Level
Particle
Acceleration
119
