4. Click OK at the clear NVRAM confirmation dialog box. The REC LED rapidly flashes
green and red; the STAT LED flashes red.
The receiver will automatically disconnect once the NVRAM is cleared.

5.6. Checking Firmware Version

Use TriVU to check the firmware version of your receiver.
1. Connect your receiver and computer. See "Connecting the Receiver and a Computer" on
page 33 for this procedure.
2. Start TriVU. Select the COM port and click Ok (Figure 5-7).
3. Click on Help About TriVU (Figure 5-13).
www.javad.com
Figure 5-12. Connection Parameters
Figure 5-13. Help->About
Receiver and File Maintenance
Checking Firmware Version
Using TriVU to Clear NVRAM
83
