On the bottom receiver's panel (Figure 1-5) there is the receiver serial number.
1.2.3. Cables
The ALPHA receiver package includes standard communication and power cables for configuring
the receiver and providing a power source to the receiver.
Receiver-to-computer RS232 serial cable – connects the
receiver's serial port and an external device (hand-held
controller or computer)
p/n p/n 14-578103-01
Receiver-to-SAE power cable – connects the receiver's
power port and the power supply's SAE connector or the
extension cable's SAE connector
p/n p/n 14-578101-01
24
Figure 1-5. ALPHA Bottom Panel
