• BAT LED - the battery status indicator. See "Powering the Receiver" on page 32 for
detailed description of the BAT LED.
Power

Back panel

• Bluetooth Antenna (optional) – Bluetooth antenna for Bluetooth wireless technology.
• GSM Antenna (optional) – This is a SMA female connector for GSM modems.
www.javad.com
BAT LED
Serial USB
Figure 1-3. ALPHA Ports
GSM Antenna
Figure 1-4. ALPHA Back Panel
External Components
Ext. Antenna
Connector
Bluetooth Antenna
Introduction
Getting Acquainted
