Using TriPad to Clear NVRAM
It is possible to clear NVRAM using only TriPad. To do that:
1. Turn the receiver OFF.
2. Press and hold FN button.
3. Press and release PWR button to turn the receiver ON.
4. Wait until both LEDs will light green.
5. Wait around five seconds, until both LEDs will blink orange.
6. Release FN button.
Note that LEDs will blink orange only during next five seconds, and to clear NVRAM it is essential to
release FN button when they blink yellow.
Using NetView to Clear NVRAM
1. Connect your receiver and computer. See "Connecting the Receiver and a Computer" on page 19
for this procedure. Start NetView. Establish connection between NetView and receiver.
2. Click on the receiver name on the left panel. On the right click on ActionsClear NVRAM.
3. Confirm NVRAM clearing.
1.7.5. Checking Firmware Version
Use NetView to check the firmware version of your receiver.
1. Connect your receiver and computer. See "Connecting the Receiver and a Computer" on page 19
for this procedure. Start NetView. Establish connection between NetView and receiver.
2. Click on the receiver name on the left panel. On the right appears the information about receiver
including receiver model, ID, firmware version.
3. To save this information to the .txt file, click ReportsReceiver info on the right panel.

1.7.6. Loading New Firmware

Base and Rover receivers must be loaded with the same firmware version. Use the latest firmware
version, available for download from the JAVAD GNSS website, to ensure your receiver has the most
recent updates. To load new firmware use NetView.
1. Connect your receiver and computer. See "Connecting the Receiver and a Computer" on page 19
for this procedure. Start NetView. Establish connection between NetView and receiver.
2. Click on the receiver name on the left panel. On the right appears the information about receiver.
3. Click ActionUpdate firmware.
4. Select the file with the mew firmware and click Open.
