Configuration
Configuring the Internal GSM Module

Configuring the GSM module for Internet access

3.1.2. Configuring the GSM module for Internet access
Note:
To comply with RF exposure requirements, maintain at least 20 cm between the user and the
GSM modem.
1. On the General tab, set the following parameters (Table 3-3) and click Apply (Figure 3-5
on page 46). In this tab modem and service status and possible errors are displayed.
Parameter
Mode
PIN
2. In the GPRS tab it is necessary to set the dial number, user name and password, access
point name and PDP context identifier to establish a GPRS connection. As usually, this
information is given by cell provider (Figure 3-6 on page 47).
PPP button opens the PPP parameters window, that allows user to set up the Point-to-Point
protocol parameters. The Point-to-Point Protocol, or PPP, is commonly used to establish a
direct connection between two nodes.
As usually, information of PPP parameters is given by Internet service provider.
46
Table 3-3. Receiver Parameters for the General Tab
Base Receiver
GPRS
Enter a Personal Identification Number (PIN) if required.
Figure 3-5. General tab
Rover Receiver
