Javad ALPHA Operator's Manual page 47

3. In the Service tab Main subtab specify the following parameters (Table 3-4) and click
Apply (Figure 3-7 on page 48).
Parameter
Mode
www.javad.com
Figure 3-6. GPRS tab
Table 3-4. Receiver Parameters for the Service Tab Main Subtab
•OFF means service is disabled.
•RCV means that modem will receive data from another (remote)
JAVAD GNSS receiver configured as a base station. This base station
have to be connected with Internet via Ethernet or GPRS and have
static IP address.
•NTRIP are useful to provide a method to establish connection to an
NTRIP caster, request data from particular mount point, and then
receive and use the data as RTK/DGPS corrections.
•SERVER - this mode allows working with JAVAD server.
Configuring the Internal GSM Module
Configuring the GSM module for Internet access
Value
Configuration
47
