Receiver and File Maintenance

Managing Receiver Options

Checking an OAF

5. Click Delete (Figure 5-6 on page 77).
6. Click Yes at the delete files confirmation dialog box. TriVU deletes the selected files.
7. Click Exit on the File Manager screen.
8. Continue with other operations. Or click File Disconnect, then File Exit to quit TriVU.
5.3. Managing Receiver Options
5.3.1. Checking an OAF
Note:
For a complete list of options and their details, visit the JAVAD GNSS website.
You can check the status of your receiver's options, and load any new OAFs, using the RS232
cable, a computer, and TriVU. Refer to the TriVU Software Manual for a more complete
description of the TriVU software.
1. Connect your receiver and computer. See "Connecting the Receiver and a Computer" on
page 33 for this procedure.
2. Start TriVU. Select the COM port and click Ok (Figure 5-7).
3. Click Tools Receiver Options. The Options Manager dialog box (Figure 5-8) contains
the following information:
• Option name – a name/description of the option
78
Figure 5-7. Connection Parameters
www.javad.com
