The Bluetooth module's processor and firmware are independent of the receiver card and power
board.

Modem

The ALPHA receiver incorporates an internal Cellular GSM/GPRS Modem with Telit® Module
(GE864 - QUAD) - GSM/GPRS single quad-band cell phone frequency modem (Europe: 900/
1800 MHz; USA and Canada: 850/1900 MHz).
Note:
To comply with RF exposure requirements, maintain at least 20 cm between the user and the
transceiver.
The Base station operator is responsible for complying with local regulations for radio operation.
In the US, the FCC regulates the use of radio transmitters, requiring a license. Broadcasting
without a license can result in severe penalties including the confiscation of your radio and GNSS
equipment.

Battery

C : Risk of explosion if battery is replaced by an incorrect type. Dispose of used battery according
AUTION
to the instructions.
The ALPHA receiver is equipped with one no removable, on-board, rechargeable Lithium-Ion
battery connected to the receiver's board. This Lithium-Ion battery is 7.2 V, 1.37 Ah.
1.2.2. External Components
The ALPHA receiver has three main panels used for data collection and user interface, and to
provide connections for external devices. The ALPHA casing includes a user interface, a power
port, and ports for configuration.
