Using Trivu To Clear Nvram - Javad ALPHA Operator's Manual

Receiver and File Maintenance
Clearing the NVRAM

Using TriVU to Clear NVRAM

3. Press and hold the power key for about 4 to 8 seconds. Release the power key while
continuing to hold the FN key.
4. Wait until the four LEDs blink yellow.
5. Release the FN key.
5.5.2. Using TriVU to Clear NVRAM
1. Connect your receiver and computer. See "Connecting the Receiver and a Computer" on
page 33 for this procedure.
2. Start TriVU. Select the COM port and click Ok (Figure 5-7).
3. Click the Tools Clear NVRAM (Figure 5-11).
82
Figure 5-10. Connection Parameters
Figure 5-11. Clear NVRAM
www.javad.com
