Bluetooth® Module Configuration - Javad ALPHA Operator's Manual

Pre-measuring Preparation
Bluetooth® Module Configuration
Establishing a USB Cable Connection
2.6. Bluetooth® Module Configuration
To access the Bluetooth® wireless technology module:
1. Connect computer and the receiver, as described in "Connecting the Receiver and a
Computer" on page 33.
2. Start TriVU. Select the COM port and click Ok (Figure 2-8).
3. Click Configuration Receiver (Figure 2-9).
4. In the Ports tab select the BLT subtab (Figure 2-10).
• Name - The name of the receiver's Bluetooth® module. Here the user can enter an
arbitrary string comprising up to 14 characters.
38
Figure 2-8. Connection Parameters
Figure 2-9. Configuration->Receiver
