Javad ALPHA Operator's Manual page 53

4. In the General tab click Set all parameters to defaults and set up the antenna parameter:
Auto or External, when external antenna is used.(Figure 3-12).
5. Click the MinPad tab and configure the following settings (Table 3-5), then click Apply
(Figure 3-13 on page 54).
For all MinPad settings see "TriPad Configuration" on page 59.
Recording interval
Elevation mask angle
File name prefix
www.javad.com
Figure 3-12. Set all parameters to defaults
Table 3-5. Receiver Parameters for the MinPad Tab
Parameter
Configuring the GSM module for Internet access
Base Receiver
Enter 15 seconds.
Enter 15 degrees.
Enter a unique ID, such as the last 3 digits of
receiver's serial number.
Configuration
Configuring the Receiver
Rover Receiver
53
