Javad ALPHA Operator's Manual page 45

Parameter
Dial number
Send time out
3. Click Apply, and then click File Disconnect.
4. If needed, launch TriVU and set up the receiver to run as an RTK Base station.
www.javad.com
Table 3-2. Receiver Parameters for the Master/Slave Tab
Base Receiver
Leave blank.
Enter a period of time in seconds in which the base/rover GSM modem will send a
service word to the rover/base GSM modem.
• This parameter is used to maintain reliable communication between a pair of
modems and avoid unnecessary modem reinitialization.
• To ensure reliable and secure modem communication, this parameter must be
larger then the period for transmitting differential corrections.
Figure 3-4. Master/Slave tab
Configuring the Internal GSM Module
Configuring the GSM module for Point-to-Point radio link
Rover Receiver
Enter the phone number of the base GSM modem.
Configuration
45
