3: Maintenance and Upgrade Procedures

Replacing Cooling System Components

Replacing the Fan Wall

94
This section provides instructions for the following procedures:
• "Replacing the Fan Wall" on page 94
• "Replacing the Hard Disk Drive Fan" on page 95
• "Replacing the Rear Fan Assembly" on page 98
Caution: Never operate the unit without all of the cooling system components in place.
Operating the workstation without the proper cooling equipment may damage the
internal components.
The fan wall cools the interface board, the PCI boards, and the graphics module. Follow
these steps to replace the fan wall (see Figure 3-33).
Note: If you have not already done so, prepare your system for service. Refer to
"Preparing the Workstation for Service" on page 49. In order to remove the fan wall, you
must remove the left side panel.
1. Disconnect the fan wall power cable from the interface board. Then remove the
screw that secures the fan wall to the chassis. If there is an XIO board support
bracket installed on the fan wall, remove the screw that secures the XIO board to the
support bracket.
2. Slide the fan wall straight out of the chassis. Place it in a secure location.
3. Slide the replacement fan wall into the enclosure. Then install the screw that secures
the fan wall to the chassis.
4. Connect the fan wall power cable to the fan wall power connector on the interface
board.
