Figure 1-4 Rear View Of The Workstation - Silicon Graphics Tezro Hardware User's Manual

007-4564-001
Line in and Line out (left)
Line in and Line out (right)
Side panel
release button
Keyboard
Mouse
Figure 1-4 Rear View of the Workstation
Audio jacks
LINE
MIC
L
+12VDC
L1 PORT IOIOI 1 IOIOI 2 CONSOLE
1.0A
R
IN OUT
DVI-I video
Setting Up the Workstation
Side panel
release button
AC power connector
CONSOLE port
IO9 PCI card
PCI gate
Kensington
lock slot
Genlock
Stereo View
7
