3.
007-4564-001
Chapter 3

Maintenance and Upgrade Procedures

This chapter provides safety information and instructions for adding or removing
components from your Silicon Graphics
covered in the following sections:
• "Safety Instructions" on page 48
• "Ordering Parts" on page 49
• "Required Tools" on page 49
• "Preparing the Workstation for Service" on page 49
• "Returning the Workstation to Service" on page 57
• "Installing or Removing a Memory DIMM" on page 63
• "Installing or Removing Internal Hard Disk Drives" on page 67
• "Installing or Removing the DVD-ROM Drive" on page 71
• "Replacing the IO9 Board" on page 76
• "Installing or Removing XIO Boards" on page 81
• "Installing or Removing PCI Boards" on page 88
• "Installing or Removing External devices" on page 93
• "Replacing Cooling System Components" on page 94
• "Replacing Internal Cables" on page 99
• "Replacing Enclosure Components" on page 106
Caution: For your own safety and to avoid damage to your equipment, do not attempt
to install or remove components that are not listed in this chapter.
® Tezro™ visual workstation. These topics are
