2: System Overview
34
provides a positive, locking connection to the SCSI backplane, which connects the disk
drives to the IO9 board (see Figure 2-9).
Figure 2-8 Hard Disk Drive Sled
IO9 board
IDE connector
Internal Hard Disk Drive Locations
Figure 2-9
SCSI connector
DVD-ROM drive
007-4564-001
Disk 2
Disk 1
