Removing an Internal Hard Disk Drive

007-4564-001
1. Open the bezel door.
Note: If you are removing the drive in the upper drive bay, ensure that the drive has
spun down before you remove it. If you are removing the drive in the lower drive bay,
you must power down the workstation.
2. Press in on the right side of the locking handle; the handle will unlatch from the
enclosure (see Figure 3-11).
3. Swing the locking handle away from the enclosure until it is fully open. Then
carefully slide the drive sled out of the drive bay. Do not pull the drive sled out by
the locking handle (see Figure 3-11).
4. If you are not installing a replacement drive, install an empty drive sled to ensure
proper airflow.
Installing or Removing Internal Hard Disk Drives
69
