3: Maintenance and Upgrade Procedures

Replacing Enclosure Components

Replacing the Enclosure Plastics

106
IO9 board
Replacing the DVD-ROM Drive Cable
Figure 3-40
This completes the replacement of the DVD-ROM drive cable. To return the workstation
to service, see "Returning the Workstation to Service" on page 57.
This section provides instructions for the following procedures:
• "Replacing the Enclosure Plastics" on page 106
• "Replacing the L1 Display" on page 108
This section contains the following procedures:
• "Replacing the Bezel Assembly" on page 107
DVD-ROM drive
.
007-4564-001
