Replacing the Bezel Assembly
Replacing the Side Plastics
Replacing the Top Plastics
007-4564-001
• "Replacing the Side Plastics" on page 107
• "Replacing the Top Plastics" on page 107
See "Removing the Enclosure Bezel" on page 54 and "Installing the Bezel" on page 58 for
instructions on replacing the bezel assembly.
See "Removing the Left or Right Side Panel" on page 52 and "Installing the Side Panels"
on page 60 for instructions on replacing the side panels.
Follow these instructions to replace the top plastic of the enclosure.
Note: If you have not already done so, prepare your system for service. Refer to
"Preparing the Workstation for Service" on page 49. In order to replace the top plastic,
you must remove the right and left side panels and the bezel.
1. Remove the six screws that secure the top plastic to the enclosure. Then lift the top
plastic off of the enclosure.
2. Align the holes in the replacement top plastic with the holes in the enclosure.
3. Install the six screws that secure the top plastic to the enclosure.
Replacing Enclosure Components
107
