Memory Upgrades

Processor Upgrades

Graphics Options

007-4564-001
The following memory upgrades are available for the workstation:
• 512-MB DIMM pair (1-processor workstations only)
• 1-GB DIMM pair
• 2-GB DIMM pair
Note: The workstation supports a maximum of eight memory DIMMs totalling 8 GB.
Memory DIMMs must be installed in pairs of the same size.
The workstation is available with 1, 2, or 4 processors. The processors are available with
several different clock speeds. Processor upgrades are accomplished by replacing the
entire system node board. 2-processor workstations can be upgraded to 4-processor
workstations by replacing the node board.
Note: 1-processor workstations cannot be upgraded with 2- or 4-processor node boards.
A variety of graphics options are available for you workstation. The following boards are
a sample of the available options:
• Dual-Channel Display (DCD-2) daughterboard
This board attaches to the VPro graphics board and allows data to be displayed
across two monitors. It has two DVI-I video ports.
• DMediaPro DM5 HD & SD Graphics to Video Output Option
This board allows direct output from graphics to video. The board is available with
or without the video break-out box (VBOB) option.
• DMediaPro DM3 HD & SD Graphics Video I/O XIO
This board allows direct input and output between graphics and video. The video
break-out box (VBOB) is included with this board.
