Replacing the DVD-ROM Drive Cable

007-4564-001
Follow the steps in this section to replace the DVD-ROM drive cable (see Figure 3-40).
Note: If you have not already done so, prepare your system for service. Refer to
"Preparing the Workstation for Service" on page 49. In order to replace the DVD-ROM
drive cable, you must remove the left side panel.
1. Open the latches on the DVD-ROM drive cable connector on the IO9 board. Then
gently disconnect the DVD-ROM drive cable from the IO9 board.
2. Disconnect the other end of the DVD-ROM drive cable from the rear of the
DVD-ROM drive and remove the cable from the enclosure.
3. Connect the replacement DVD-ROM drive cable to the rear of the DVD-ROM drive.
Note that the cable is keyed: ensure that you are aligning the cable in the connector
correctly.
4. Connect the replacement DVD-ROM drive cable to the IO9 board. Note that the
cable is keyed: ensure that you are aligning the cable in the connector correctly.
5. Close the latches on the DVD-ROM drive cable connector. Then gently press the IO9
board into the interface board to ensure that it is firmly seated in its connectors.
