PC Modem Serial Cable

007-4564-001
Note: For a 3-wire cable and no hardware flow control modem, you must use the
/dev/ttyd* command devices in the configuration files. For more detailed
information, see the serial man page. To access the man page, select Help > Man
pages from the Toolchest or place the cursor in the console window and type man
serial.
Table A-6 Printer/Dumb Terminal Cable Pinout
Pin Number
Signal DB-9 Connector
Description (Female)
1
RXD 2
TXD 3
4
GND 5
6
7
8
9
Use a full-handshake (includes RTS and CTS) PC modem serial cable for a modem with
RTS/CTS flow control. Table A-7 shows the cable connector pin assignments for this
cable.
You can use this cable for all serial devices except those that do not need RTS flow control.
If you add a null modem adapter to one end of the cable, you can still use it with devices
like serial printers and dumb terminals that do not need RTS flow control. You can
purchase the full-handshake PC modem serial cable from SGI or your local service
provider.
Serial Cables and Adapter Specifications
Pin Number
DB-25 Connector (Male)
NOT CONNECTED
2
3
NOT CONNECTED
7
NOT CONNECTED
NOT CONNECTED
NOT CONNECTED
NOT CONNECTED
133
