NOTE
For the PC settings, refer to your PC's operation manual.
(2) Mechanical Serious Errors
Table 9-5 Symptoms and Check Items for Mechanical Serious Errors
No. Message
1 E 065 error
PF motor
AP-74109 Rev 1.1
Event/ Check item
symptom
Abnormal 1. Check error history
condition in PF from "Test7:
motor (X-axis) Record." of self-
during printer diagnosis function.
operation.
2. Set the number of
Displayed if
endurance running
the difference
cycles to 50 or more
between motor
from "Check10:
command
Endurance" of
value and
"Life2: PF Motor"
feedback from
of self-diagnosis
encoder is
function, and check
large.
if "X motor error"
occurs.
3. Check "Encoder:
PF" from "Test5:
Encoder" of self-
diagnosis function.
4. PF motor assembly
may be defective.
5. Main board
assembly may be
defective.
ValueJet 1304 Service manual
-
Check connection of
following main board
assembly connectors.
• PF motor cable
assembly
connector: J20
• PF_ENC assembly
connector: J12
• If NG, check
connection of main
board assembly
connector: J12.
• Replace PF motor
assembly.
• Replace main board
assembly.
9-14
Action Reference
"5.5.7
History
Menu" p.5-18
"4.3.3
Replacing
Main Board
Assembly"
p.4-29
"4.4.1
Replacing PF
Motor
Assembly"
p.4-44
"4.3.3
Replacing
Main Board
Assembly"
p.4-29
