ValueJet 1304 Service manual
Table 2-1 Part Names and Functions of Front Section (Continued)
No. Name
9 Platen
2.3.2

Rear Section

8
9
No. Name
1 AC inlet
2 Network interface
connector
3 USB connector
4 Scroller receiver
5 Media feed slot
6 Ink cartridge slot
7 Media guide
8 Waste fluid tank
This is inside the front cover.
There are heaters (platen heater) inside to dry ink.
Table 2-2 Part Names and Functions of Rear Section
For inserting the power cable plug.
Connector to connect a network interface cable.
This printer does not support the connector.
The scroller is set here when using roll media.
Insert media from here when feeding media.
This holds the ink cartridge.
Supports the media to be feed smoothly when media setting and printing.
There are pre heaters inside to warm the media.
This is a tank that contains the waste ink.
Function
K
C
M Y
6 4
Function
2-5
5
7
4
1
3 2
AP-74109 Rev 1.1
