Table 2-2 Part Names and Functions of Rear Section (Continued)
No. Name
9 Waste fluid valve
2.3.3 Winding unit
6
7
No. Name
1 Winding unit
2 Cushioning roller
3 Scroller receiver
4 Scroller release lever
5 Scroller
6 Scroller height fixing
screw
7 Scroller height
adjustment screw
8 Horizontal adjustment
screw
9 Power switch
AP-74109 Rev 1.1
Open this valve to discharge the waste fluid from the waste fluid tank.
In other case, close the valve.
3
Table 2-3 Part Names and Functions of Winding Unit
Winds the printed media.
Loads the printed media to the winding unit.
Used when setting the scroller of the winding unit.
Releases the scroller from the winding unit, allowing you to turn the
scroller with your hand.
Used when winding the printed media.
Fix the height of the scroller receiver.
Adjust the height of the scroller receiver.
Adjust the side position of the scroller.
Used when turning the power ON and OFF.
Function
2
5
1
Function
2-6
ValueJet 1304 Service manual
9
10
4 8
