8.4 Lubrication/Bonding

This section covers the lubrication/bonding information.
After disassembling/assembling this printer, always perform necessary lubrication/bonding according to
Table 8-4"Lubricant List"(p.6).
CAUTION
Only use specified lubricants and greases. The use of unauthorized lubricants and greases
may damage the components and shorten the printer life.
Parts
Cover section Roll receiver
(L, R)
Front cover
support pin L
CR section Cursor guide
Pressure
shaft bearing
Pressure
shaft stopper
Head section Head cable
Cable guide CR cable
section
Tube guide
Others Screw
Table 8-4 Lubricant List
Item Manufacturer
Apply to the top Dow Corning
cover contacting Toray Co.,Ltd.
surface.
Apply to the top Dow Corning
cover contacting Toray Co.,Ltd.
surface.
Apply to the front Mitsubishi
surface.
Apply to the Dow Corning
peripheral surface. Toray Co.,Ltd.
Apply to the Dow Corning
pressure lever Toray Co.,Ltd.
springs.
Affix to each cable Not specified
(for locating and
holding)
Affix to each cable Not specified
(for locating)
Affix to the tube Not specified
guide (for
locating)
Apply to the area Three Bond
screw-locking Co., Ltd.
agent is applied.
8-7
Type Exploded
view
MOLYKOTE
(R)EM-60L
GREASE
MOLYKOTE
(R)EM-60L
GREASE
Super multi-
dia tetrat
No.32
MOLYKOTE
(R)EM-60L
GREASE
MOLYKOTE
(R)EM-60L
GREASE
10mm- width
double faced
tape
10mm-width
double faced
tape
10mm-width
double faced
tape
