ValueJet 1304 Service manual
1
12. Remove the damper locating material-retaining screw (round head spring screw M3
1
13. Remove the damper locating material.
表 4-73
2
表 4-74
2
4-65
No. Part name
1 Flat-head driver insertion point
2 Damper assembly
No. Part name
1 Damper locating material
2 Damper locating material screw
(round head spring screw M3
6 W sems)
×
6 W sems: 2).
×
AP-74109 Rev 1.1
