General Information
Modulating Dehumidification Module (1U15 IntelliPak II) (1U107 IntelliPak I)
(Optional - used with Dehumidification Control)
The MDM supports specific control inputs and outputs for Modulating Dehumidification
control including modulating Reheat and Cooling valve control as well as the Reheat
Pumpout Coil Relay output.
Generic Building Automation System Module (1U10 = GBAS 0-5V, 1U11 = GBAS
0-10V IntelliPak II) (1U51 = GBAS 0-5V/0-10V IntelliPak I) (Optional - used with
Non-Trane Building Control System)
The Generic Building Automation System (GBAS) module allows a non-Trane building
control system to communicate with the unit and accepts external SETPOINTs in form
of analog inputs (0 - 5 V or 0 - 10 V depending on the module selected) and a binary
Input for demand limit. Five (5) binary outputs are available on 0 - 5 V modules. One (1)
binary output and four (4) analog outputs are available on the 0 - 10 V modules. Refer to
the "Field Installed Control Wiring" section of the Unit Installation, Operation,
Maintenance Manual (IOM) for the control wiring to the GBAS module and the various
desired SETPOINTs with the corresponding DC voltage inputs.
Ventilation Override Module (VOM) (1U8 IntelliPak II) (1U53 IntelliPak I)
(Optional - used on units with special ventilation requirements)
The Ventilation Override module can control the unit's air handling functions to perform
customer specified functions such as space pressurization, exhaust, purge, unit off, etc.
Interprocessor Communications Board (IPCB) (1U12 IntelliPak II) (1U55
IntelliPak I) (Optional - used with Optional Remote Human Interface)
The Interprocessor Communication Board expands communications from the unit UCM
network to a Remote Human Interface Panel. DIP switch settings on the IPCB module for
this application should be; Switches 1 and 2 "Off" , Switch 3 "On" .
BACnet Communication Interface Module (BCI) (1U66 IntelliPak II) (1U104
IntelliPak I) (Optional - used on units with Trane ICS or 3rd party Building
Automation Systems)
The BACnet Communication Interface module expands communications from the unit
UCM network to a Trane Tracer Summit, or a 3rd party building automation system that
utilizes BACnet, and allows external SETPOINT and configuration adjustment and
monitoring of status and diagnostics.
Lontalk Communication Interface Module (LCI) (1U7 IntelliPak II) (1U65
IntelliPak I) (Optional - used on units with Trane ICS or 3rd party Building
Automation Systems)
The LonTalk Communication Interface module expands communications from the unit
UCM network to a Trane Tracer Summit, or a 3rd party building automation system that
utilizes LonTalk, and allows external SETPOINT and configuration adjustment and
monitoring of status and diagnostics.
