Human Interface Module - Trane IntelliPak I Programming, Troubleshooting Manual

General Information
Human Interface Module (Local = 1U2, Remote = 9U13 IntelliPak II) (1U65 IntelliPak I)
The Human Interface (HI) Module illustrated in
customer, building owner, or contractor, to communicate to the Rooftop unit the
necessary parameters for unit operation such as cooling and heating SETPOINTs,
demand limiting, ventilation override modes, etc.
The local (unit mounted) Human Interface and the Remote Human Interface Panel
functions are identical, except for Service mode which is not available on the Remote
Human Interface Panel.
The local HI Module is located in the unit's main control panel. A small door located in
the unit's control panel door allows access to the HI Module's keypad and display
window.
There is a 2 line by 40 character LCD screen which provides status information for the
various unit functions as well as menus used to set or modify the operating parameters.
There is a 16 key keypad adjacent to the LCD screen, which allows the operator to scroll
through the various menus and make adjustments to the SETPOINTs, etc.
The information displayed in the LCD window will be top-level status information
unless the operator initiates other displays.
At power-up, the Human Interface LCD will display one of four initial screens illustrated
in the "General Status" section.
1.
2. Unit Status (Unit On) (The unit is configured and operational, and is running). This
3. VOM Active (a ventilation override command was received) This screen shows that
4. No Configuration (the unit needs to be configured). This screen shows that required
The LCD screen has a backlight that makes the information easier to read. The light will
go out if no keys are pressed for 30 minutes. If it goes out, simply press the STATUS
key.
10
Unit Status (Unit Off or Stopped) (The unit is configured and operational, but is not
running). This screen shows state, mode, and function information when the unit is
off or stopped.
screen shows state, mode, and function information when the unit is on.
the unit is in a Ventilation Override Mode.
configuration data is missing.
Figure 1 is the device which enables the
RT-SVP04F-EN
