General Information

VOM Active

If at power up the unit is running and has entered a Ventilation Override mode of
operation, the following display will appear on the Human Interface LCD screen.

No Configuration

If at power up the unit has not been programmed with the necessary configuration data
for normal unit operation, the following display will appear on the Human Interface LCD
screen. When this screen is being displayed, the only functional key is the
CONFIGURATION key.
Note: This screen will only appear when the RTM has been field replaced. Refer to the

Factory Presets

The UCM controlled unit has many operating functions which are preset at the factory,
but may be modified to meet the unique requirements of each job. The following list
identifies each of the unit's adjustable functions and the value assigned to it. If these
factory presets match the application's requirements, simply press the AUTO key at the
Human Interface module to begin unit operation (after completing the Pre-Start and
Start-Up procedures in the Installation, Operation, and Maintenance manual). If the
application requires different settings, turn to the listed page beside the function, press
the designated function menu key, then press and hold the NEXT or PREVIOUS key
until its screen appears on the LCD. Once the proper screen appears, simply follow the
programming instructions given below the applicable screen in this manual.
Note: Record any changes made to the factory-preset values in the corresponding
18
Ventilation Override Mode
Configuration Menu.
No Configuration Present
Press Configuration Key
space provided.
VO Mode in Operation
(A,B,C,D,E)
______
_____________
Trouble Indicator
(Blank)
(Diagnostics)
RT-SVP04F-EN
