System Testing & Troubleshooting
OA Damper Pos 0%
1. Press the + or - key until the proper value is displayed.
2. Press the ENTER key to confirm this choice.
3. Press the NEXT key until the following screen is displayed.
4. Repeat steps 1 and 2 for the next value.
5. Press the NEXT key until the following screen is displayed (if
applicable)
Ventilation Override Module Output Relay
OFF
1. Press the + or - key until the proper value is displayed.
2. Press the ENTER key to confirm this choice
3. Press the NEXT key until the following screen is displayed.
VCM Preheater State
1. Press the + or - key until the proper value is displayed.
2. Press the ENTER key to confirm this choice
3. Press the NEXT key until the following screen is displayed.
GBAS 0-5 VDC Module Relay Outputs
#1 OFF #2 OFF #3 OFF
1. Press the + or - key until the proper value is displayed.
2. Press the ENTER key to confirm this choice.
3. Press the NEXT key until the following screen is displayed.
4. Repeat steps 1 and 2 for the next value.
5. Press the NEXT key until the following screen is displayed (if
applicable)
GBAS 0-10 VDC Module Relay Outputs
#1 OFF
1. Press the + or - key until the proper value is displayed.
2. Press the ENTER key to confirm this choice.
3. Press the NEXT key until the following screen is displayed.
4. Repeat steps 1 and 2 for the next value.
5. Press the NEXT key until the following screen is displayed (if
applicable)
114
Exhaust Damper: 0%
Exhaust Fan: OFF
OFF
#4 OFF #5 OFF
Used With: All units; OA Damper
Pos (Fresh Air) shown if 100%
Economizer* or 25% Motorized OA
Damper installed
Exhaust (Damper) shown only if
Power Exhaust or Return Fan with
Statitrac is installed
Exhaust Fan shown only if Power
Exhaust (no Return Fan) is installed
(with or without Statitrac)
Possible Values: OA Damper: 0 to
100% (Economizer installed) or 0-
25% (Motorized OA Damper
installed); Exhaust Damper= 0-
100%; Exhaust fan= OFF, ON
Used With: All Units when VOM is
installed
Factory Presets: OFF
Possible Values: ON, OFF
Used With: All Units when VCM is
installed
Factory Presets: OFF
Possible Values: ON, OFF
Used With: All Units when GBAS 0-
5 VDC is installed
Factory Presets: OFF
Possible Values: 1, 2, 3, 4, 5 =
ON, OFF
Used With: All Units when GBAS 0-
10 VDC is installed
Possible Values: OFF, ON
RT-SVP04F-EN
