Configuration - Model Num Digit
BAS Communication Module
1. Press the + or - key until the proper value is displayed.
2. Press the ENTER key to confirm this choice.
3. Press the NEXT key until the following screen is displayed.
Configuration - Model Num Digit
GBAS 0-5 VDC Module
1. Press the + or - key until the proper value is displayed.
2. Press the ENTER key to confirm this choice.
3. Press the NEXT key until the following screen is displayed.
Configuration - Model Num Digit
GBAS 0-10 VDC Module
1. Press the + or - key until the proper value is displayed.
2. Press the ENTER key to confirm this choice.
3. Press the NEXT key until the following screen is displayed.
Configuration - Model Num Digit
Ventilation Override (VOM)
1. Press the + or - key until the proper value is displayed.
2. Press the ENTER key to confirm this choice.
3. Press the NEXT key until the following screen is displayed.
Unit Model Number
1. Pressing the NEXT key will scroll forward through the screens.
2. Pressing the PREVIOUS key will scroll backwards to view the
previously displayed screen.
Software Revision Number:
RTM
1. Pressing the NEXT key will scroll forward through the screens.
2. Pressing the PREVIOUS key will scroll backwards to view the
previously displayed screen.
Note: "INVALID" shown in upper right corner if s/w version not valid for unit w/IntelliPak II config jumper.
RT-SVP04F-EN
34 or 35 Used With: All Units
INSTALLED Possible Values: CONFIG REQ'D, NOT
INSTALLED, INSTALLED
34 or 28 Used With: All Units
INSTALLED Possible Values: CONFIG REQ'D, NOT
INSTALLED, INSTALLED
34 or 28 Used With: All Units
INSTALLED Possible Values: CONFIG REQ'D, NOT
INSTALLED, INSTALLED
34 or 31 Used With: All Units
INSTALLED Possible Values: CONFIG REQ'D, NOT
INSTALLED, INSTALLED
Used With: All units unless RTM has
been changed.
Possible Values: Model Number
INVALID Used With: Screen always shown
24.00 Possible Values: Software Revision
Number: See note below; RTM (before
the period): 0-255; RTM (after the
period): 00-99
System Configuration
