Trane IntelliPak I Programming, Troubleshooting Manual page 41

Active Unoccupied Zone Heating STP From
HI (KEYPAD) SETPOINT MENU
1. Pressing the NEXT key will scroll forward through the screens.
2. Pressing the PREVIOUS key will scroll backwards to view the
previously displayed screen.
3. Press the + (Plus) key while viewing any screen to add that
screen to the custom menu. Refer to the custom menu for the
creation and maintenance of customized menus.
4. Press the NEXT key until the following screen is displayed.
(if applicable)
Active Morning Warmup SETPOINT From
HI (KEYPAD) SETPOINT MENU
1. Pressing the NEXT key will scroll forward through the screens.
2. Pressing the PREVIOUS key will scroll backwards to view the
previously displayed screen.
3. Press the + (Plus) key while viewing any screen to add that
screen to the custom menu. Refer to the custom menu for the
creation and maintenance of customized menus.
4. Press the NEXT key until the following screen is displayed.
(if applicable)
Active Occ Dehumidification Setpt From
HI (KEYPAD) SETPOINT MENU
1. Pressing the NEXT key will scroll forward through the screens.
2. Pressing the PREVIOUS key will scroll backwards to view the
previously displayed screen.
3. Press the NEXT key until the following screen is displayed.
(if applicable)
Active Unocc Dehumidification Setpt From
HI (KEYPAD) SETPOINT MENU
1. Pressing the NEXT key will scroll forward through the screens.
2. Pressing the PREVIOUS key will scroll backwards to view the
previously displayed screen.
3. Press the NEXT key until the following screen is displayed.
(if applicable)
Active Supply Air Reheat Setpoint From
HI (KEYPAD) SETPOINT MENU
1. Pressing the NEXT key will scroll forward through the screens.
2. Pressing the PREVIOUS key will scroll backwards to view the
previously displayed screen.
3. Press the NEXT key until the following screen is displayed.
(if applicable)
RT-SVP04F-EN
Is 60 F
Is 72 F
is 60%
is 60%
is 70.0°F
System Operating Status
Used With: All Units when Gas,
Electric, Hydronic or External Heat is
installed
Possible Values: HI (Keypad)
SETPOINT Menu, NSB Panel
SETPOINT Input, GBAS 0-5 VDC
Module, BAS/Network, GBAS 0-10
VDC Module; Range 50 - 88F
Used With: All Units when Gas,
Electric, Hydronic or External Heat is
installed
Possible Values: HI (Keypad)
SETPOINT Menu Zone Sensor Setpnt
Input, NSB Panel SETPOINT Input,
GBAS 0-5 VDC Module, BAS/
Network, GBAS 0-10 VDC Module;
Range: 52 - 90 F
Used With: All IntelliPak units with
Dehumidification installed.
Possible Values: HI (KEYPAD)
SETPOINT MENU, BAS/NETWORK,
GBAS 0-5VDC Module, BAS/
Network, GBAS 0-10 vdc Module;
Range= 40 to 65%
Used With: All IntelliPak units with
Dehumidification installed.
Possible Values: HI (KEYPAD)
SETPOINT MENU, BAS/NETWORK,
GBAS 0-5VDC Module, BAS/
Network, GBAS 0-10 vdc Module;
Range= 40 to 65%
Used With: All IntelliPak units with
Dehumidification installed.
Possible Values: HI (KEYPAD)
SETPOINT MENU, BAS/NETWORK,
GBAS 0-5VDC Module, BAS/
Network, GBAS 0-10 vdc Module;
Range= 60 to 80 F
41
