Trane IntelliPak I Programming, Troubleshooting Manual page 103

Note: For DISCH TEMP CTRL (VAV) possible value, this indicates with IGV/VFD.
Note: For DISCH TEMP CTRL (CV) possible value, this indicates without IGV/VFD.
Configuration - Model Num Digit
Fresh Air Section:
1. Press the + or - key until the proper value is displayed.
2. Press the ENTER key to confirm this choice.
3. Press the NEXT key until the following screen is displayed.
Configuration - Model Num Digit
Ventilation Ctrl (VCM) CONFIG REQ'D
1. Press the + or - key until the proper value is displayed.
2. Press the ENTER key to confirm this choice.
3. Press the NEXT key until the following screen is displayed.
Note: For Ventilation Ctrl (VCM) NOT INSTALLED possible value, this screen used to indicate
Ventilation Ctrl module NOT INSTALLED. There are two possible VCM "installed" options.
Configuration - Model Num Digit
Comparative Enthalpy:
1. Press the + or - key until the proper value is displayed.
2. Press the ENTER key to confirm this choice.
3. Press the NEXT key until the following screen is displayed.
Configuration - Model Num Digit
Final Filters:
1. Press the + or - key until the proper value is displayed.
2. Press the ENTER key to confirm this choice.
3. Press the NEXT key until the following screen is displayed.
Configuration - Model Num Digit
Energy Recovery:
1. Press the + or - key until the proper value is displayed.
2. Press the ENTER key to confirm this choice.
3. Press the NEXT key until the following screen is displayed.
Note: This feature not permitted to be installed if Return Fan is already installed.
RT-SVP04F-EN
21 or 16 Used With: All Units
No Fresh Air Possible Values: CONFIG REQ'D, NO
FRESH AIR, 0-100% ECONOMIZER, 0-
25% MOTORIZED DAMPER
21 or 31 Used With: All Units
Possible Values:
* Ventilation Ctrl (VCM) CONFIG REQ'D,
* Ventilation Ctrl (VCM) NOT INSTALLED
* Fresh Air Measurement(VCM) W/ DCV
OPTION
* OA Damper Min Pos (VCM) W/ DCV
OPTION
21 or 23 Used With: Screen always shown
INSTALLED Possible Values: CONFIG REQ'D, NOT
INSTALLED, INSTALLED
24 Used With: All IntelliPak II Units
INSTALLED Possible Values:CONFIG REQ'D, NOT
INSTALLED, INSTALLED
25 Used With: All IntelliPak II Units with
Energy Recovery installed
NOT INSTALLED
Possible Values: CONFIG REQ'D, NOT
INSTALLED, INSTALLED W/O PREHEAT,
INSTALLED W/ PREHEAT
System Configuration
103
