System Programming SETUP
Assign Diagnostic to Alarm Output?
________________________
1. Press the + or - key until the proper value is displayed.
2. Press the ENTER key to confirm this choice.
3. Press the NEXT key to advance the cursor.
4. Repeat steps 1 and 2 for the next value.
5. Press the NEXT key until the following screen is displayed
(if applicable).

Assignment Submenu - HEAT Alarms

Press ENTER to Review or Adjust
1. Pressing the NEXT key will bypass this section.
Assign Diagnostic to Alarm Output?
_________________________
1. Press the + or - key until the proper value is displayed.
2. Press the ENTER key to confirm this choice.
3. Press the NEXT key to advance the cursor.
4. Repeat steps 1 and 2 for the next value.
5. Press the NEXT key until the following screen is displayed
(if applicable).

Assignment Submenu - ECEM Alarms

Press ENTER to Review or Adjust
1. Pressing the NEXT key will bypass this section.
Assign Diagnostic to Alarm Output?
_________________________
1. Press the + or - key until the proper value is displayed.
2. Press the ENTER key to confirm this choice.
3. Press the NEXT key to advance the cursor.
4. Repeat steps 1 and 2 for the next value.
5. Press the NEXT key until the following screen is displayed
(if applicable).
76
YES
YES
YES
Used With: All units. (if ENTER
pressed above)
Possible values: YES/NO; Lvg Evap
Temp Sensor Fail - Ckt 1, Lvg Evap
Temp Sensor Fail - Ckt 2, Low Pres
Control Open - Ckt 1, Low Pres
Control Open - Ckt 2, Cond Temp
Sensor Failure - Ckt 1, Cond Temp
Sensor Failure - Ckt 2, Compressor
Trip - Ckt 1, Compressor Trip - Ckt
2, MCM Communications Failure,
Comp, Contactor Fail - Ckt 1, Comp
Contactor Fail - Ckt 2, High Super
Heat - Ckt 1, Low Refrigerant
Charge - Ckt 1, High Super Heat -
Ckt 2, Low Refrigerant Charge - Ckt
2, Enter Evap Temp Sensor Fail -Ckt
1, Enter Evap Temp Sensor Fail -Ckt
2
Used With: All units with Heat
installed. (if "Any Active Diagnostic"
NO is selected above)
Used With: All units with Heat
installed. (if ENTER pressed above)
Possible values: YES/NO; HEAT
Aux Temp Sensor Fail, Low Air Temp
Limit Trip, Heat Failure, Heat Module
Comm Failure
Used With: All units. (if "Any Active
Diagnostic" NO is selected above)
Used With: All units with ECEM
installed. (if ENTER pressed above)
Possible values: YES/NO; Space
Static Pres Setpt Failure, Space
Pressure Sensor Failure, Return Air
Temp Sensor Failure, RA Humidity
Sensor Failure, ECEM
Communications Failure
RT-SVP04F-EN
