Trane IntelliPak I Programming, Troubleshooting Manual page 86

System Programming SETUP
Actuator Setup
Max Voltage
1. Press the + or - key until the proper value is displayed.
2. Press the ENTER key to confirm this choice.
3. Press the NEXT key until the following screen is displayed.
Actuator Setup
Max Voltage
1. Press the + or - key until the proper value is displayed.
2. Press the ENTER key to confirm this choice.
3. Press the NEXT key until the following screen is displayed.
Note: Only one of the following two screens will be shown
Actuator Setup
Direct/Reverse Act
1. Press the + or - key until the proper value is displayed.
2. Press the ENTER key to confirm this choice.
3. Press the NEXT key until the following screen is displayed.
Actuator Setup
Direct/Reverse Act
1. Press the + or - key until the proper value is displayed.
2. Press the ENTER key to confirm this choice.
3. Press the NEXT key until the following screen is displayed.
Actuator Setup
Max Stroke Time
1. Press the + or - key until the proper value is displayed.
2. Press the ENTER key to confirm this choice.
3. Press the NEXT key until the following screen is displayed.
Actuator Setup
Min Voltage
1. Press the + or - key until the proper value is displayed.
2. Press the ENTER key to confirm this choice.
3. Press the NEXT key until the following screen is displayed.
86
Num 2 Low Ambient
10.0 VDC
Cond Fan VFD Ckt 2
10.0 VDC
Num 2 Low Ambient
DIRECT ACTING
Cond Fan VFD Ckt 2
DIRECT ACTING
Modulating Gas Heat
90 Sec
Modulating Gas Heat
2.0 VDC
Used With: All Units with Air-
Cooled Condensers installed
Factory Presets: 10.0 VDC
Possible Values: 0.1 to 10.0 Volts
DC
Used With: All IntelliPak II units
with water-cooled condensers
installed.
Factory Preset: 10.0 VDC
Possible Values: 0.0 - 10.0 VDC
Used With: All Units with Air-
Cooled Condensers installed
Factory Presets: Direct Acting
Possible Values: Direct Acting,
Reverse Acting
Used With: All IntelliPak II units
with water-cooled condensers
installed.
Factory Preset: DIRECT
Possible Values: DIRECT, REVERSE
Used With: All Rooftop Units and
Air Handlers when Modulating Gas is
installed
Factory Presets: 90 Seconds
Possible Values: 1 - 255 Seconds
Used With: All Rooftop Units and
Air Handlers when Modulating Gas is
installed
Factory Presets: 2 VDC
Possible Values: 0.0 to 9.9 Volts
DC
RT-SVP04F-EN
