General Information
Table 1. RTM Resistance Input vs. Setpoint Temperatures
RTM cooling or heating
setpoint input used
as the source for
a ZONE temp setpoint (°F)
40
45
50
55
60
65
70
75
80
n/a
n/a
Table 2. RTM Resistance Value vs. System Operating Mode
Resistance applied to RTM MODE
input Terminals (Ohms)
Max. Tolerance 5%
2320
4870
7680
10770
13320
16130
19480
27930

Compressor Modules

(SCM & MCM - 1U49 standard on all units)
The compressor modules, (Single Circuit & Multiple
Circuit), upon receiving a request for mechanical cooling,
energizes the appropriate compressors and condenser
fans. It monitors the compressor operation through
feedback information it receives from various protection
devices.

Human Interface Module

(HI - 1U65 standard on all units)
The Human Interface module enables the operator to
adjust the operating parameters for the unit using it's 16
key keypad.The 2 line, 40 character LCD screen provides
status information for the various unit functions as well as
menus for the operator to set or modify the operating
parameters.
12
RTM cooling setpoint input
used as the source
for SUPPLY AIR temp
setpoint cooling (°F)
40
45
50
55
60
65
70
75
80
85
90
Constant Volume/SZVAV Units
Fan Mode
Auto
Auto
Auto
On
On
On
Auto
On
Resistance (Ohms) Max.
Tolerance 5%
1084
992
899
796
695
597
500
403
305
208
111
System Mode
Off
Cool
Auto
Off
Cool
Auto
Heat
Heat

Heat Module

(1U50 used on heating units)
The Heat module, upon receiving a request for Heating,
energizes the appropriate heating stages or strokes the
Modulating Heating valve as required.
Modulating Dehumidification Module
MDM
(Optional 1U107 - used with Dehumidification
Control)
The MDM supports specific control inputs and outputs for
Modulating Dehumidification control including
Modulating Reheat and Cooling valve control as well as
the Reheat Pumpout Relay output.The Modulating
Dehumidification control Algorithm provides control
requests to the MDM to accomplish proper
Dehumidification control.
RT-SVX36K-EN
