Trane IntelliPak Programming Manual

With symbio 800, 20 to 75 ton with the tracer td7 display
Hide thumbs Also See for IntelliPak:
Table of Contents

Advertisement

Quick Links

See also: User Manual , Installation Operation & Maintenance
Programming Guide
IntelliPak™ with Symbio™ 800, 20 to 75 Ton
with the Tracer
Only qualified personnel should install and service the equipment. The installation, starting up, and servicing
of heating, ventilating, and air-conditioning equipment can be hazardous and requires specific knowledge and
training. Improperly installed, adjusted or altered equipment by an unqualified person could result in death or
serious injury. When working on the equipment, observe all precautions in the literature and on the tags,
stickers, and labels that are attached to the equipment.
December 2018
®
TD7 Display
SAFETY WARNING
RT-SVP011A-EN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IntelliPak and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Trane IntelliPak

Summary of Contents for Trane IntelliPak

  • Page 1 Programming Guide IntelliPak™ with Symbio™ 800, 20 to 75 Ton ® with the Tracer TD7 Display SAFETY WARNING Only qualified personnel should install and service the equipment. The installation, starting up, and servicing of heating, ventilating, and air-conditioning equipment can be hazardous and requires specific knowledge and training.
  • Page 2 Introduction Warnings, Cautions, and Notices Safety advisories appear throughout this manual as required. Your personal safety and the proper operation of this machine depend upon the strict observance of these precautions. The three types of advisories are defined as follows: Indicates a potentially hazardous situation which, if not avoided, could result in WARNING death or serious injury.
  • Page 3 Introduction Copyright This document and the information in it are the property of Trane, and may not be used or reproduced in whole or in part without written permission. Trane reserves the right to revise this publication at any time, and to make changes to its content without obligation to notify any person of such revision or change.

  • Page 4: Table Of Contents

    Table of Contents Introduction ............6 Hardware .
  • Page 5 Table of Contents Creating a Data Graph ......... . 31 Settings .

  • Page 6: Introduction

    The Tracer TD7 is a durable factory-mounted touch screen display that is designed to operate in both indoor or outdoor environments. The TD7 display utilizes a standard 75mm VESA mounting pattern for installation in a Trane Large enclosure. Alternatively, it can be installed with a user- supplied VESA mount.

  • Page 7: Dimensions

    Introduction Dimensions 7.9 in. (200.7 mm) 8.3 in. (211.6 mm) 2.1 in. (53.2 mm) 1.7 in. (41.9 mm) 5.5 in. (139.9 mm) 6.3 in. (158.8 mm) Note: The power cable is permanently attached to the TD7 display. The power connector provides strain relief and protection from the elements.

  • Page 8: Specifications And Agency Compliance

    Tracer TU Service Tool Version 10.2 or higher is only required for TGP2 and modifications done in the field. Note: Tracer TU is not needed for normal operation. If you need to perform configuration changes, add new features, or customize the operation of the equipment, contact your local Trane office. Web UI...

  • Page 9: Supported Languages

    Introduction Supported Browsers for Tracer Symbio Web UI Microsoft Windows 7: • Internet Explorer 11 (limited support) • Mozilla Firefox (most recent version) • Google Chrome (most recent version) Microsoft Windows 8.1: (no support) Microsoft Windows 10: • Internet Explorer 11 (no support) •...

  • Page 10: Screen Overview

    Introduction Screen Overview There are three distinct areas on the TD7 screens: • Top display area • Main display area • Bottom display area Figure 2. Tracer TD7 display screen Top display area Main display area Bottom display area Top Display Area The Back button, when touched, returns to the previous screen visited.

  • Page 11: Main Display Area (Home Screen)

    Introduction Main Display Area (Home Screen) The Home screen is an overview of the unit and its operation. High-level status information is presented so that a user can quickly understand the mode of operation of the unit and navigate quickly to other areas of the display for more detail. Figure 3.
  • Page 12 Introduction Touch this button to navigate to the Reports screen. Touch this button to open the Data Graphs screen to view and/or edit data logs in graphical format. Touch this button to open the Settings screen, which contains options for manual controls, Feature settings, Binding, Unit Settings, and display settings.

  • Page 13: Alarms

    Alarms Alarms appear on the Tracer TD7 display immediately upon detection. Touch the Alarms button in the bottom display area to view the Alarms screen. Active Alarms Figure 4 shows the Active Alarms screen and commonly used functions. Configuration is not required in order for points in alarm to appear in the Active Alarms screen.

  • Page 14: Viewing Active Alarms

    Alarms Figure 6. Web UI Alarms screen Viewing Active Alarms • Active alarms: These are alarms that require attention. All alarms that are currently active appear when you view this category. Active alarms are not reset by way of the display. Active alarms will clear automatically when the condition causing the alarm is removed.

  • Page 15: Sorting Alarms

    Alarms Table 1. Alarm icons Active Alarm Icons Notification Class Critical Service Required Warning Information None Note: Notifications classes are configured in point alarm settings section in Tracer TU. Sorting Alarms To sort alarms by a category other than date and time, touch one of the other column headings in the table.
  • Page 16 Alarms Figure 7. Web UI Alarm Configuration screen RT-SVP011A-EN...

  • Page 17: Reports

    Reports You can use the Tracer TD7 Display to view a variety of reports and create and edit custom reports. Touch the Reports button in the bottom display area to view the Reports screen. The Reports screen contains the following buttons: •...
  • Page 18 Reports Figure 9. Creating a custom report 3. Use the up and down arrow buttons to select a point type. Add items by touching the item that is highlighted blue, then touch the Add button. 4. Continue adding values to your report. When you are finished, touch the Save button. The Custom Report screen, populated with your selected values, appears (Figure 10).

  • Page 19: Editing A Custom Report

    Reports Editing a Custom Report 1. Touch Reports to view the Reports screen. 2. Touch the report that you want to edit. Follow steps 2 through 4 in “Creating a Custom Report,” p. 17. to complete your edits. Figure 11. Editing a custom report Up and down arrows: Up and down...

  • Page 20: All Points Report

    Reports Figure 12. Custom Report (order of items) Custom Report All Points Report Touch the All Points Report button to view the All Points Report screen, which contains all configured points for the unit controller. Use the up and down arrows located at the right most bottom of the screen to page up or down.

  • Page 21: Points Overrides

    Reports Figure 14. Web UI Points Points Overrides Point Overrides are used to allow control of values, such as setpoints used for the operation of the equipment. These can be time based or persist until they are released. From the Point Override screen you can perform overrides, set them to expire in a user-defined interval, or release a point that is currently overridden.

  • Page 22: Binary Overrides

    Reports Override Status Area This area shows who is controlling the point, followed by the active priority level and the current value of the point. If security is enabled, the name of the user that performed the override will be shown in the Controlled By field.

  • Page 23: Multistate Overrides

    Reports Multistate Overrides Multistate override screens that contain five or more items will contain up and down arrow buttons in the Override setting area. Use the up and down arrow buttons to select a state. Touch the Apply or Save button to retain your changes.

  • Page 24: Setting Up A Temporary Override

    Reports Figure 18. Displaying the analog keypad screen Touch the keypad icon to open the Analog keypad screen. Enter a value by tapping the numerals on the keypad. Touch Enter to save and return to the Override screen. Keypad Icon Analog Keypad Screen Setting Up a Temporary Override You can set up a temporary override by using the buttons in the Temporary Override area.

  • Page 25: About

    Reports The Override Summary screen contains all active overrides. Columns are sortable and automatically default to Time Remaining. The override icon ( ) indicates that a point override is in effect indefinitely. The temporary override icon ( ) indicates that an override will expire after a specified duration. To release all overrides in the list, touch the Release All Overrides button (only points that are controlled at priority level 8 will be released).
  • Page 26 This is the name that was assigned to the Symbio 800. Unit Model Number This is the model number of the IntelliPak/equipment on which the Symbio 800controller is installed. This value is typically entered in the factory, but can be entered in the controller.

  • Page 27: Expansion Modules

    Reports Figure 21. Web UI Resource Usage Figure 22. Web UI Identification and Communications Expansion Modules Touch the Expansion Module button to view the Expansion Modules screen. If expansion modules have been installed, they will appear in Expansion Modules screen (Figure 23).
  • Page 28 Reports Figure 23. Expansion modules screen Expansion module screen columns: Address — This is the rotary address of the defined or discovered expansion module. Status — Under normal conditions, OK will display in this column. If not refer to “Tracer XM30, XM32, XM70, and XM90 Expansion Modules IOM,”...

  • Page 29: Tgp2 Programs

    Reports TGP2 Programs Touch the TGP2 Programs button to view the TGP2 Programs screen. All TGP2 programs that have been installed on the controller appear here. The program name, status, run type, and interval for each program is provided. Interval is the scheduled run interval for the program and is displayed in HH:MM:SS.

  • Page 30: Using The Trend Viewer

    Reports order to make room for the newest data. A list of data logs can be accessed by clicking Data Logs from the left navigation menu. From this page you can take action on a data log, such as comparing or exporting, by selecting one or more data logs and then clicking the Actions button.

  • Page 31: Data Graphs

    Data Graphs Data graphs allow users to view trend logs from the controller in graphical format on the TD7 Display. Up to eight data graphs can be created with a maximum of four data logs per graph. Data graphs are user-defined and can be edited by changing the scale on the left and right Y-axis and choosing the line color.
  • Page 32 Data Graphs Figure 28. Edit Data Graph screen 3. Touch the Add/Remove button to add values to the custom data graph. The Add/Remove screen appears. 4. Use the arrow buttons to select a datalog type: analog, binary, or multistate, which then populates the box directly below.
  • Page 33 Data Graphs 7. Use the Edit Data Graph screen to modify the data graph. Touch the Edit button that corresponds with the value that you want to change. Only one value can be edited at a time. Figure 30. Edit Data Graph screen (after values have been added) 8.
  • Page 34 Data Graphs 9. Touch the View Data Graph button to display the new graph (Figure 32). Note: Depending on the sampling rate, the custom data graph may be empty for several hours. You can make changes to the way data is presented on the graph at anytime. Touch the zoom-in icon and zoom-out icon to either increase or decrease the viewable time frame.
  • Page 35 Data Graphs Figure 33. Repeat steps 2 through 4 until all preferred changes have been made. Editing the Y-Axis RT-SVP011A-EN...

  • Page 36: Settings

    Settings The Settings screen provides options for display settings, language, overrides and security.Touch the Settings button in the bottom display area to view the Settings screen. Three categories for settings appear on the screen: • Control Settings • Equipment Settings •...

  • Page 37: Equipment Settings

    Settings Figure 35. LLID Binding Equipment Settings Unit Settings Unit Settings are the basic parameters for unit operation. Feature Settings Features Settings allows you to enable or disable features and functions. Manual Overrides Manual Overrides are temporary overrides that can be used to test equipment and features. The override time is adjustable from 1 - 78 hours.

  • Page 38: Display Settings

    Settings Figure 36. Manual Override screen Override Status Area This area shows who is controlling the point, followed by the active priority level and the current value of the point. If security is enabled, the name of the user that performed the override will be shown in the Controlled By field.
  • Page 39 Settings Figure 37. Web UI User Preferences Figure 38. Display Preferences screen Date Format Touch the Date Format button to open the associated screen. Three options are available to display the current date: MMDDYYYY, DDMMYYYY, and YYYYMMDD. Date Separator Touch the Date Separator button to open the associated screen. Three options are available to display separators in the date format: None, Hyphen (-), or Slash (/).
  • Page 40 Settings Number Format Touch the Number Format button to open the associated screen. Two options are available: period format (1000.0) or comma format (1000,0). First Day of the Week Touch the First Day of the Week button to open the associated screen. Specify the starting day for the week when viewing schedules and adding events.

  • Page 41: Language

    Settings Figure 40. Home Page screen Figure 41. Web UI Home Page Language Touch the Language button, or the language icon ( ) located at the bottom right of each screen, to open the open the Language screen. Three languages are available and represented on the selection buttons.

  • Page 42: Date And Time

    Settings Figure 42. Language screen Figure 43. Web UI Login screen Date and Time Touch the Date and Time button to open the associated screen. To enter a new date or time, touch the digit you want to change. When enabled for editing, the digit will appear red with a black border. when finished, touch Apply or Save.

  • Page 43: Clean Touchscreen

    Settings Figure 44. Date and Time screen Clean Touchscreen Touch the Clean Touchscreen button to safely clean the TD7 touchscreen using any brand of common household glass cleaner. When this button is touched, the screen background color becomes black, allowing dirt and fingerprints to become more visible. It also displays a countdown timer (five to zero seconds).Touch the screen anytime within the 5-second countdown to begin cleaning the screen (each touch resets the 5-second countdown).

  • Page 44: Optimal Start/Stop

    Settings Optimal Start/Stop Optimal start and stop times can be defined for HVAC schedules. HVAC refers to both Area and equipment. The schedule coordinates with the Area application or equipment to calculate when the optimal start and stop occurs. Optimal start/stop times are based on outside air conditions, space temperature, and occupied setpoints.

  • Page 45: The Tools Menu

    Settings Note: A Release is a predetermined time in which the present schedule or the event releases control over to the next event based on priority. A scheduled Release is very similar to a timed point override. 7. Add events to the schedule: click add event, which opens the event dialog box. 8.

  • Page 46: Programs

    From the left navigation menu click Tools > System Logs. Recent Usage Resource Usage displays system usage among applications, memory, and points. This is primarily used by Trane Technical support. BACnet Information Information about BACnet configurations is shown on this page. This information is typically used by Trane Technical Support.

  • Page 47: Regional Specifications

    Identification and Communication The Identification and Communications page allows you to view and edit configurations for the equipment name, location name, Protocol, IP and network address settings, Air-Fi configuration, Trane Intelligent Services, and network connectivity. It is divided into seven tabs. RT-SVP011A-EN...

  • Page 48: Usb Ports And Microsd

    Settings Figure 50. Identification and Communications USB Ports and microSD On this page, you can view the USB ports and microSD for your Symbio 800. In addition, you can enable and disable individual USB ports and safely unmount mass storage devices from the USB ports and microSD.

  • Page 49: Configuring Additional Settings

    Settings Figure 52. Product License Configuring Additional Settings Additional settings such as user preferences, application defaults, SMTP settings, languages, and background may be modified here. Defaults for User Preferences The Defaults page shows the formats in which the system displays data. This page is divided into two sections: Regional Preferences and Data Display Units.

  • Page 50: Smtp Settings

    Settings Figure 54. Application Defaults SMTP Settings Use to set up your Simple Mail Transfer Protocol (SMTP) so that events can be routed to users by e-mail. Figure 55. SMTP Settings Priority Levels Priority levels establish a strategy used by the system to avoid conflicting control by giving precedence to applications with a higher level of priority.

  • Page 51: Login Page

    Settings Login Page On the Login page you can upload language packs and personalize your login page by adding background images. Figure 57. Login Page RT-SVP011A-EN...

  • Page 52: Troubleshooting

    Troubleshooting Troubleshooting This section describes the possible error messages and other issues that you may encounter while using the Tracer TD7 display. Identifying and Diagnosing Issues Active Diagnostic Name Affects Modes Reset Severity Persistence Criteria and Source Target [Inactive Level Modes] VFD Fault Supply Unit...
  • Page 53 Troubleshooting Active Diagnostic Name Affects Modes Reset Severity Persistence Criteria and Source Target [Inactive Level Modes] VFD Supply Fan Unit Warning with Latching The inverter peak current of approximately 200% of rated Local Motor Current Special Action current was exceeded for 1.5 seconds. Overload - 1 This is a drive enforced lockout.
  • Page 54 Troubleshooting Active Diagnostic Name Affects Modes Reset Severity Persistence Criteria and Source Target [Inactive Level Modes] VFD Supply Fan Unit Warning with Latching An earth ground fault has resulted in a discharge from the Local Ground Fault – 1 Special Action output phases to ground, either in the cable between the adjustable frequency drive and the motor or in the motor VFD Supply Fan...
  • Page 55 Troubleshooting Active Diagnostic Name Affects Modes Reset Severity Persistence Criteria and Source Target [Inactive Level Modes] VFD Supply Fan Unit Warning with Latching A short circuit in the motor windings or the motor terminals was Local Short Circuit – 1 Special Action detected.
  • Page 56 Troubleshooting Active Diagnostic Name Affects Modes Reset Severity Persistence Criteria and Source Target [Inactive Level Modes] VFD Fault Relief Unit Normal Latching VFD Fault. Numerous drive faults can cause this general Local Fan - x Shutdown with fault. Reference the EBM-PAPST Installation and Operating manual for a list of fault codes and VFD Fault Relief Special Action...
  • Page 57 Troubleshooting Active Diagnostic Name Affects Modes Reset Severity Persistence Criteria and Source Target [Inactive Level Modes] VFD Fault Circuit Warning Latching VFD Fault. Numerous drive faults can cause this general Local Condenser Fan - fault. Reference the TR170 Installation and Operating with Cktx manual for a list of fault codes and descriptions.
  • Page 58 Troubleshooting Active Diagnostic Name Affects Modes Reset Severity Persistence Criteria and Source Target [Inactive Level Modes] VFD Condenser Unit Warning Non-latching The drive has been put into hand mode at the drive Local Fan In Hand Mode interface. This will cause issues for normal sequences –...
  • Page 59 Troubleshooting Active Diagnostic Name Affects Modes Reset Severity Persistence Criteria and Source Target [Inactive Level Modes] VFD Compressor Circuit Immediate Latching Cprsr A short circuit in the motor windings or the motor Local Short Circuit– Energized terminals was detected. Compressor operation is not Shutdown Cprsr1A recommended until the short circuit is removed.
  • Page 60 Troubleshooting Active Diagnostic Name Affects Modes Reset Severity Persistence Criteria and Source Target [Inactive Level Modes] Unexpected Circuit Immediate Latching A non-command shutdown of the fixed speed compressor Local Compressor occurred. The controller detected that the input was not Shutdown Shutdown proven.
  • Page 61 Troubleshooting Active Diagnostic Name Affects Modes Reset Severity Persistence Criteria and Source Target [Inactive Level Modes] Low Suction Circuit Immediate Latching The suction pressure dropped below a pressure threshold Local Pressure Cktx as described below: Shutdown Low Suction When the circuit is not running, or for Reduced Pressure Cktx Threshold Time seconds immediately after the circuit Low Suction...
  • Page 62 Troubleshooting Active Diagnostic Name Affects Modes Reset Severity Persistence Criteria and Source Target [Inactive Level Modes] Supply Air High Unit Immediate Latching The supply air pressure has exceeded the Supply Air Remote Static Pressure Pressure High Limit Setpoint the 3 consecutive time Shutdown Lockout...
  • Page 63 Troubleshooting Active Diagnostic Name Affects Modes Reset Severity Persistence Criteria and Source Target [Inactive Level Modes] Emergency Unit Warning Non-Latching All The unit is following Emergency Override Pressurize. Local Override Mode Pressurize Emergency Override Mode Pressurize Emergency Override Mode Pressurize Emergency Unit Warning...
  • Page 64 Troubleshooting Active Diagnostic Name Affects Modes Reset Severity Persistence Criteria and Source Target [Inactive Level Modes] Discharge Air Iso Unit Immediate Latching The Discharge Air Isolation Damper operation was less Remote Damper Failed to Shutdown than 80% open after 5 minutes. Open Discharge Air Iso Damper Failed to...
  • Page 65 Troubleshooting Active Diagnostic Name Affects Modes Reset Severity Persistence Criteria and Source Target [Inactive Level Modes] Supply Fan 1 Unit Warning with Latching Any time the Supply Fan is expected to be running in Non Remote Proving Failure Special Action Bypass Mode, this diagnostic will be generated when a No Flow condition exists for 40 continuous seconds.
  • Page 66 Troubleshooting Active Diagnostic Name Affects Modes Reset Severity Persistence Criteria and Source Target [Inactive Level Modes] Suction Circuit Immediate Latching The suction temperature sensor has failed out of range. Remote Temperature 2 Shutdown Cktx Suction Temperature 2 Cktx Suction Temp Sensor Suction Pressure Circuit...
  • Page 67 Troubleshooting Active Diagnostic Name Affects Modes Reset Severity Persistence Criteria and Source Target [Inactive Level Modes] Starts/Hours Cprsr Warning Non-Latching All The current value for the cumulative compressor starts Remote Modified - and or hours for the given compressor have been Cprsrxy modified by a write override from TU.
  • Page 68 Troubleshooting Active Diagnostic Name Affects Modes Reset Severity Persistence Criteria and Source Target [Inactive Level Modes] Relief Air Damper Unit Warning Non- Latching All The relief air damper position has been lower than the Remote Failed Closed damper command by 10% for 5 continuous minutes. Relief Air Damper Failed Closed Rlf ir Damper Fail...
  • Page 69 Troubleshooting Active Diagnostic Name Affects Modes Reset Severity Persistence Criteria and Source Target [Inactive Level Modes] Hydronic Heat Unit Warning Non- Latching All The hydronic heat actuator position has been greater Remote Actuator Failed than the actuator command by 10% for 5 continuous Open minutes.
  • Page 70 Troubleshooting Active Diagnostic Name Affects Modes Reset Severity Persistence Criteria and Source Target [Inactive Level Modes] Outdoor Air Unit Warning Non-Latching All The Active Outdoor Air Humidity sensor has failed out of Humidity Sensor range. with Active Special Outdoor Air This drives a ‘fall back’...
  • Page 71 Non-Latching All ID chip contains invalid data, or contains a different Remote Chip Manf X heating configuration than what is installed on the Trane controller. All burners on the manifold are unavailable Heat Invalid ID until the condition is corrected.
  • Page 72 Troubleshooting Active Diagnostic Name Affects Modes Reset Severity Persistence Criteria and Source Target [Inactive Level Modes] Heat Control Heat Warning Non-Latching All Gas heat control detects an internal failure. All burners on Remote Board Failure the manifold are unavailable until the condition is Manf X corrected.
  • Page 73 Troubleshooting Active Diagnostic Name Affects Modes Reset Severity Persistence Criteria and Source Target [Inactive Level Modes] Heat Inducer Low Heat Warning Non-Latching All Staged Gas Heat control boards only. Remote Press Manf X A ‘Heat Inducer Low Press Manf X’ condition has occurred Slave on the 1285’s own MODBUS slave control board on the Heat Inducer Low...
  • Page 74 Troubleshooting Active Diagnostic Name Affects Modes Reset Severity Persistence Criteria and Source Target [Inactive Level Modes] Space Unit Warning VVZT/CVZT: VVZT/CVZT: VVZT/CVZT: Unit Shutdown Temperature Latching VVDA/CVDA: Unit continues to operate and disables the Space VVDA/ following functions. VVDA/ Temperature CVDA: All Unoccupied modes (heat, cool, DH), Space...
  • Page 75 Troubleshooting Active Diagnostic Name Affects Modes Reset Severity Persistence Criteria and Source Target [Inactive Level Modes] Comm Loss: Unit Warning Non-Latching All Continual loss of communication between the MP and the Remote Return Air Functional ID has occurred for a 30 - 35 second period. with Temperature This drives a ‘fall back’...
  • Page 76 Troubleshooting Active Diagnostic Name Affects Modes Reset Severity Persistence Criteria and Source Target [Inactive Level Modes] Comm Loss: VFD Unit Normal Latching Continual loss of communication between the MP and the Remote Relief Fan – x VFD has occurred for a 30 second period. Comm Loss: VFD Relief Fan –...
  • Page 77 Troubleshooting Active Diagnostic Name Affects Modes Reset Severity Persistence Criteria and Source Target [Inactive Level Modes] Comm Loss: Circuit Immediate Latching Continual loss of communication between the MP and the Remote Suction Functional ID has occurred for a 30 second period. Shutdown Temperature 1 Cktx...
  • Page 78 Troubleshooting Active Diagnostic Name Affects Modes Reset Severity Persistence Criteria and Source Target [Inactive Level Modes] Comm Loss: Circuit Immediate Latching Continual loss of communication between the MP and the Remote Condenser Fan Functional ID has occurred for a 30 second period. Shutdown Relay 4 Cktx Comm Loss:...
  • Page 79 Troubleshooting Active Diagnostic Name Affects Modes Reset Severity Persistence Criteria and Source Target [Inactive Level Modes] Comm Loss: EXV Circuit Immediate Latching Continual loss of communication between the MP and the Remote 1 Cktx EXV Step Status has occurred for a 30 second period, OR Shutdown EXV Steps Maximum Position has not been received.
  • Page 80 Troubleshooting Active Diagnostic Name Affects Modes Reset Severity Persistence Criteria and Source Target [Inactive Level Modes] Comm Loss: Unit Immediate Latching Continual loss of communication between the MP and the Remote Return Air Return Air Isolation Damper has occurred for a 30 second Shutdown Isolation Damper period.
  • Page 81 Troubleshooting Active Diagnostic Name Affects Modes Reset Severity Persistence Criteria and Source Target [Inactive Level Modes] Comm Loss: Unit Normal Latching Continual loss of communication between the MP and the Remote Staged Electric Shutdown Functional ID has occurred for a 30 second period. Heat Relay 2 Comm Loss: Staged Electric...
  • Page 82 Troubleshooting Active Diagnostic Name Affects Modes Reset Severity Persistence Criteria and Source Target [Inactive Level Modes] Invalid Active Unit Warning Non-Latching All No Valid Input from BAS or Unit. Disables Traq Remote Outdoor Airflow Invalid Active Outdoor Airflow Invalid Active OA Flow Invalid Active Unit...

  • Page 83: Td7 Automatic Rediscover And Automatic Hardware Reboot

    Troubleshooting Active Diagnostic Name Affects Modes Reset Severity Persistence Criteria and Source Target [Inactive Level Modes] Comm Loss: Unit Warning Non-Latching All Continual loss of communication between the MP and the Remote Power Meter Functional ID has occurred for a 30 second period. Comm Loss: Power Meter Comm: Power...
  • Page 84 Troubleshooting Automatic rediscovery (Updating data): • Add a new point • Remove a point • Rename a point • Modify Display Preferences or Language (from TU) • Modify Custom Report or Header Data Point (from TU) Automatic restart of TD7: This will occur when modifying security settings: when a first and last user is added and deleted (enables, disables security), or when the restarts.

  • Page 85: Notes

    Notes Notes RT-SVP011A-EN...
  • Page 86 Notes RT-SVP011A-EN...
  • Page 87 Notes RT-SVP011A-EN...
