Active Min OA Flow SETPOINT From
HI (KEYPAD) SETPOINT MENU
1. Press the NEXT key until the following screen is displayed. (if applicable)
Active Design Min OA Flow SETPOINT
From HI (KEYPAD) SETPOINT MENU
1. Press the NEXT key until the following screen is displayed. (if applicable)
Active Min OA Flow Stp DCV Disabled
1. Press the NEXT key until the following screen is displayed. (if applicable)
Active Supply Air Pressure STP From
HI (KEYPAD) SETPOINT MENU
1. Press the NEXT key until the following screen is displayed.
Active Supply Air Pressure SETPOINTS
High Limit: 4.0 IWC
1. Press the NEXT key until the following screen is displayed.
RT-SVP04F-EN
34.2 CFM
34.2 CFM
is 2.0 IWC
Deadband: 0.5 IWC
System Operating Status
Used With: All Units when Fresh
Air Measurement VCM is installed
Possible Values: HI (Keypad)
SETPOINT Menu, GBAS 0 - 5 VDC
Module, BAS Network GBAS 0-10
VDC Module SETPOINT range: 0 to
Max Unit Airflow
Refer to the table in the SETPOINT
section, "Default Min OA Flow
SETPOINT Screen" for max airflow
SETPOINTs.
Used With: All Units when Fresh
Air Measurement VCM is installed
Possible Values: HI (Keypad)
SETPOINT Menu, GBAS 0 - 5 VDC
Module, BAS Network GBAS 0-10
VDC Module SETPOINT range: 0 to
Max Unit Airflow
Refer to the table in the SETPOINT
section, "Default Min OA Flow
SETPOINT Screen" for max airflow
SETPOINTs.
Used With: All Units when Fresh
Air Measurement VCM is installed
Possible Values: HI (Keypad)
SETPOINT Menu, GBAS 0 - 5 VDC
Module, BAS Network GBAS 0-10
VDC Module SETPOINT range: 0 to
Max Unit Airflow
Refer to the table in the SETPOINT
section, "Default Min OA Flow
SETPOINT Screen" for max airflow
SETPOINTs.
Used With: Rooftop units and Air
Handlers when IGV/VFD is installed.
Possible Values: HI (Keypad)
SETPOINT Menu, GBAS 0-5 VDC
Module, GBAS 0-10 VDC Module,
BAS/Network SETPOINT Range:
0.7=5.1 IWC
Used With: Rooftop units and Air
Handlers with IGV/VFD installed or
with SAP present.
Possible Values: High Limit: 1.2 -
4.7 IWC Deadband: 0.1 - 2.0 IWC
