Ricoh SCRIPT2 Setup Manual page 346

Using RICOH-SCRIPT2 with Windows
❖ ❖ ❖ ❖ Copies
Use this to set the number of copies of a print job.
Note
❒ With some applications, the number of copies specified with the applica-
1
tion takes priority over the number of copies specified with the printer
driver.
❖ ❖ ❖ ❖ Custom
Select [Custom page] in [Paper size], and then click [Custom]. This will open the
[Custom-Defined Size] dialog box where you can set the custom page size.⇒ P.3
"[Custom-Defined Size] dialog box"
❖ ❖ ❖ ❖ More Options
Click to open the [More Paper Options] dialog box. ⇒ P.2 "[More Paper Options]
dialog box"
You can select the page orientation for duplex printing and the paper type in
this dialog box.
Limitation
❒ Duplex printing is possible only when the PAPER FEED UNIT Type206
(option) and the AD390 (duplex unit, option) are installed on the printer.
❖ ❖ ❖ ❖ About
Click to display the printer driver copyright and version information.
[More Paper Options] dialog box
❖ ❖ ❖ ❖ Printing on both sides (duplex printing)
Use this to set the duplex printing. The following items are available: [None],
[Flip on long edge] and [Flip on short edge].
Limitation
❒ Duplex printing is possible only when the PAPER FEED UNIT Type206
(option) and the AD390 (duplex unit, option) are installed on the printer.
Note
❒ You can select long-edge feed or short-edge feed regardless of feed and
print direction.
❖ ❖ ❖ ❖ Paper type
Use this to select the paper type. The following items are available: [Plain Pa-
per], [OHP Transparency], and [Thick Paper].
Note
❒ Selecting [OHP Transparency] as the paper type automatically adjusts inter-
nal settings to use a color profile specifically for OHP transparencies. Even
though the color profile has been optimized for OHPs, the adjustments are
automatic and are not indicated in any of the dialog boxes. In this case, the
"Color Profile" setting on the [Device Options] tab is not enabled.
