Printing Preferences Tabs and Their Settings

Limitation
❒ Changing the printer settings requires Manage Printers permission. Members
of the Administrators and Power Users groups have Manage Printers permis-
sion by default. When you set up options, log on using an account that has
Manage Printers permission.
❒ General users can change the settings in an application's [Print] dialog box.
[Layout] tab
❖ ❖ ❖ ❖ Print on Both Sides (Duplex)
Use this to set the duplex printing.
The following items are available: [None], [Flip on Short Edge] and [Flip on Long
Edge].
Limitation
❒ Duplex printing is possible only when the PAPER FEED UNIT Type206
(option) and the AD390 (duplex unit, option) are installed on the printer.
Note
❒ You can select long-edge feed or short-edge feed regardless of feed and
print direction.
❖ ❖ ❖ ❖ Advanced
Click to open the [Advanced Options] dialog box. ⇒ P.10 "[Advanced Options]
dialog box"
[Paper/Quality] tab
❖ ❖ ❖ ❖ Tray Selection
• Paper Source
Use this to select the tray from which you want paper to be fed for printing.
The following items are available: [Automatically Select], [Tray 1], and [Tray 2]
(option).
Note
❒ If you cannot select an optional tray even though it is physically in-
stalled on the printer, use [Installable Options] on the [Device Settings] tab
to correctly set up the option.
• Media
Use this to select the paper type as [Plain Paper], [OHP Transparency], or [Thick
Paper].
