Using RICOH-SCRIPT2 with a Macintosh
Note
❒ Selecting [OHP Transparency] as the paper type automatically adjusts in-
ternal settings to use a color profile specifically for OHP transparencies.
Even though the color profile has been optimized for OHPs, the adjust-
ments are automatic and are not indicated in any of the dialog boxes. In
this case, the "Color Profile" setting on [Option] is not enabled.
• Duplex
2
Use this to set the duplex printing.
The following items are available: [Off], [Short Edge] and [Long Edge].
Limitation
❒ Duplex printing is possible only when the PAPER FEED UNIT Type206
(option) and the AD390 (duplex unit, option) are installed on the print-
er.
Note
❒ You can select long-edge feed or short-edge feed regardless of feed and
print direction.
• Statistics Code
Use this to set [On] or [Off].
If [On] is selected, User Code "99999999" and User ID "RPS2" will be fixed.
If [Off] is selected, User Code "Other" and User ID "?" will be fixed.
Reference
For more information about User Codes, see the "Printer Reference" in-
cluded as a PDF file on the CD-ROM.
LaserWriter 8.4x or later
The following describes the settings specific to this printer using LaserWriter
8.4x or later.
Reference
For more information about LaserWriter 8.4x or later, see the documentation
that comes with your Macintosh.
❖ ❖ ❖ ❖ Selecting [Color Matching] in the [Printer] dialog box shows the following items:
• Print Color
You can specify the method and the color conversion settings for printing.
The following items are available.
• [Black and White]
Select this for monochrome printing.
• [Color/GrayScale]
If you select this item, the color profile you select in "Color Profile" of
[Printer Specific Options] becomes effective.
