2. Orient the new fan in the same position as the fan that you removed. Make sure
3. Push the fan assembly down into the server until the blue mounting grommets
4. Connect the cable of the replacement fan into the connector.
5. Close the fan door.
6. Slide the server into the rack.

Removing the battery

To remove the battery, complete the following steps:
1. Read the safety information that begins on page vii and "Installation guidelines"
2. Turn off the server and peripheral devices and disconnect the power cords and
3. Remove the cover (see "Removing the cover" on page 61).
4. See "System-board internal connectors" on page 8 for the location of the
5. Remove the battery:
that the airflow indicator, on the top of the fan, is pointing to the rear of the
server
.
are correctly seated.
on page 57
all external cables.
battery.
a. Use a non-conductive alignment tool to press the top of the battery clip
away from the battery. The battery pops up when it is released.
b. Lift and remove the battery from the socket.
Fan 2
O W O W
F L F L
A IR A IR
Fan 3
Chapter 4. Removing and replacing server components
W
L O
R F
A I
Fan 4
Fan 5
87
